Accepted CAD & Drawing Formats
3D CAD models are preferred for quoting and machining review. Include a 2D drawing when tolerances, threads, GD&T, surface finishes,
or other critical requirements must be controlled.
or other critical requirements must be controlled.
STEP / STP
SLDPRT
IPT
IGES / IGS
Parasolid
X_T / X_B
DWG / DXF
FILE REQUIREMENTS
What to Include With Your Files
Providing these details helps us review your project faster and prepare a more accurate quote.
Material
Quantity
Tolerances
Surface Finish
Critical Features
NDA & File Confidentiality
Your CAD files and drawings are handled confidentially.
Project files are used only for quotation, engineering review, and manufacturing purposes.
Access to project files is limited to authorized personnel involved in your project.
NDA Available Upon Request
We can review and sign your NDA before you share confidential CAD files, drawings, or project information.
Ready to Send Your Files?
Upload your CAD files, drawings, and project requirements for a fast manufacturing review and quote.
FAQ
File Formats & NDA FAQs
Common questions about CAD file formats, drawings, and confidentiality.
What if my files are too large to upload?
If your files are too large for the quote form, contact us by email and we can arrange a suitable file transfer method.
What is the best CAD file format to send?
STEP or STP is preferred for most CNC machining projects because it provides reliable 3D geometry for quoting and engineering review.
Can I send only a STEP file?
Yes. A STEP file is often sufficient for an initial quote. For critical tolerances, threads, GD&T, surface finishes, or inspection requirements, please also provide a 2D drawing.
Can you sign my NDA before I send files?
Yes. We can review and sign your NDA before you share confidential CAD files, drawings, or project information.
Can I upload 2D drawings with my 3D model?
Yes. We recommend submitting 2D drawings with your 3D CAD model when dimensions, tolerances, threads, GD&T, surface finishes, or other critical requirements need to be specified.
